CDIL – BD139 – NPN Epitaxial Silicon Power Transistors

CDIL – BD139 – NPN Epitaxial Silicon Power TransistorsOverview:These epitaxial planar transistors are mounted in the TO126 plastic package. They are designed for audio amplifiers and drivers utilizing complementary or quasi-complementary circuits.The NPN types are the BD135 and BD139, and the complementary PNP types are the BD136 and BD140.Features:Products are pre-selected in DC current gainApplication:General purposeSpecifications:Type:Bipolar Transistors – BJTRoHS:RoHSTransistor Polarity:NPNCollector- Base Voltage VCBO:100 V   Collector- Emitter Voltage VCEO Max:80 VEmitter- Base Voltage VEBO:5 VMaximum Operating Temperature: 150 CPackage / Case:TO126Minimum Operating Temperature:– 55 CPackaging:PlasticPd – Power Dissipation:8 WProduct Manuals / Spec Sheets / Downloads:To download datasheet, Please click Here.
