DAC-1.0mH I Core Inductor Crossover Coil – 16AWG

DAC-1.0mH I Core Inductor Crossover Coil – 16AWG  Overview:DAC 16 gauge iron core inductors are the most cost effective choice when large inductance values are needed for subwoofer crossovers. Features fully annealed refined copper wire with baked enamel insulation, wrapped around a laminated iron core. Highlights:Iron core constructionHighly refined copper wireBaked enamel insulator250 watts RMS power handling±5% Tolerance Product Description:DAC 16 gauge iron core inductors are the most cost effective choice when large inductance values are needed for subwoofer crossovers. Features fully annealed refined copper wire with baked enamel insulation, wrapped around a laminated iron core. All DAC iron core inductors are constructed on a  long plastic bobbin around a 80*30mm laminated iron core. Specifications:Inductance1.0 mHWire gauge16 AWGCore typeIronDC resistance0.11 ohmsTolerance±5%Power handling250 watts RMSDimensions80*30mm Copper quality/purity: The copper used in all DAC inductors, both wire and foil based, is a minimum of 99.9% pure, providing 100% conductivity. The oxygen component of the copper is between 0.02% and 0.04%.Technical note: To prevent crosstalk and noise position inductors in crossovers at right angles to each other.
