DAC-0.85mh Air Core Inductor Crossover Coil – 20AWG

DAC-0.85mh Air Core Inductor Crossover Coil – 20AWGOverview:The DAC air core inductors are precision wound with high-purity copper wire to a ± 2% tolerance. A special varnishing process bonds the wires throughout the inductor, eliminating the possibility of FM distortion. The perfect layer air core construction improves heat dissipation while eliminating hysteresis and any type of saturation distortion. All the inductors have been manufactured with a very tight tolerance so as to avoid worry about matched pairs. Proudly Made in INDIA!Specifications:Inductor TypeAir CoreTolerance± 2%Inductance0.85 mHWire gauge20 AWGDC resistance0.67 OhmsDimensions (Approx.)24 mm H x 42 mm DPower handling200 Watts RMSFeatures:No saturation distortion due to air-core design. Inductors contain no magnetic materials.Optimum winding tension and high dimensional stability.Tight tolerance of 2%.High power handling and extreme precision.Almost perfectly pure copper coil.Superb product consistency for more accurate filter performance.Amazing musicality and soundstage.Applications:Passive crossover circuitZobel Network circuitBaffle step compensation circuitNote:We do have custom inductor coil winding service, Please click Here, to e-mail us your requirement with the following parameters to get the quotation.Inductor value in mHWire gauge in AWGCore type (Air, Ferrite)Quantity
