DSE6120 MKIII – Auto Mains (Utility) Failure Control Module, 24V DC

Main Features Standard CAN communication port, built-in J1939 protocol, has matched more than 30 kinds of engines; Various kinds of parameters display. Input/output function, status can be shown directly. More categories of surface setting. Real time clock inside: preset time operate and auto maintenance is available. Genset working plan can be set as per week or month. Three class protection countdown function, which can set the maintenance time or date. The black box function can save the relevant parameters of the unit when the fault alarm occurs in real time, and it is convenient to find the cause of the fault. Totally 7relay’s output, among which 5 relay output can be self-configurable, each relay can be set as max 50 functions, besides, there are 4 groups as non-contact terminals. With 5 switchesinput, up to 40 functions optional; 4sensor simulation input connectors,  the oil pressure sensor is compatible with voltage signal input, and various display units can be configured. Battery charging control function,which can protect the battery according to battery voltage status. Sensor can be self-defined by front face button or PC software. Adapt to 3P4W,1P2W,2P3W(120V/240V,50/60HZ) Various of crank conditions (RPM, Frequency, Oil Pressure) can be chosen. Control Protection: Auto Start/Stop of genset, load transfer (ATS control) and perfect failure display and protection. Standard water-proof rubber gasket. The waterproof can reach IP54
