DSE6020 MKII – Auto Mains (Utility) Failure Control Module, 24V DC

The DSE 6020 MKII is an Auto Mains (Utility) Failure Control Module developed to provide a wide range of operating and monitoring features for single diesel and gas gen-sets. KEY FEATURES • Support for 0-10 V & 4-20mA oil pressure senders. • Large back-lit icon LCD display. • Heated display option. • 3-phase generator sensing. • 3-phase generator and mains (utility) sensing. • Breaker control buttons on front fascia. • Generator & load power monitoring (kW, kV A, kV Ar, pf). • Generator overload protection (kW). • Generator/load current monitoring & protection. • Configurable analogue/digital inputs. • Configurable DC, volt-free and staged loading outputs. • CAN, MPU & alternator speed sensing (selectable depending on engine type). • Tier 4 CAN engine support. • Configurable event log (50). • DSE Configuration Suite PC Software. • Fuel and start outputs (configurable on CAN). Category: Controller Modules Tag: DSE6020 MKII - Auto Mains (Utility) Failure Control Module
